5.4.4 PICTURE and WHITE BALANCE adjustment values memory area tables
The memory area PICTURE and WHITE BALANCE adjustment values have the layout shown below. Adjustment in
memory mode uses the same memory as Color mode 1, and 2. The adjustment values in integrator mode are stored in
parts of memory separate from that for color mode 1 and 2.
Integrator Mode
¥CONTRAST
¥BRIGHT.
¥COLOR
¥TINT
¥SHARP
IN1–525i
INPUT1(VIDEO) ★
525i
625i
525p
625p
1125i/60Hz
1125i/50Hz
750p
1125p
¥CONTRAST
¥BRIGHT
¥COLOR
¥TINT
¥H.SHARP
¥V.SHARP
IN1–525i Color mode 1
¥CONTRAST
¥BRIGHT
¥COLOR
¥TINT
¥H.SHARP
¥V.SHARP
IN1–525i Color mode 2
¥R HIGH
¥G HIGH
¥B HIGH
¥R LOW
¥G LOW
¥B LOW
INPUT1(PC)
PC#1
PC#2
PC#3
PC#4
PC#5
PC#6
PC#7
PC#8
¥R HIGH
¥G HIGH
¥B HIGH
¥R LOW
¥G LOW
¥B LOW
¥CONTRAST
¥BRIGHT.
¥COLOR
¥TINT
¥SHARP
IN2–525i
INPUT2(VIDEO) ★
525i
625i
525p
625p
1125i/60Hz
1125i/50Hz
750p
1125p
¥CONTRAST
¥BRIGHT
¥COLOR
¥TINT
¥H.SHARP
¥V.SHARP
IN2–525i Color mode 1
¥CONTRAST
¥BRIGHT
¥COLOR
¥TINT
¥H.SHARP
¥V.SHARP
IN2–525i Color mode 2
¥R HIGH
¥G HIGH
¥B HIGH
¥R LOW
¥G LOW
¥B LOW
¥R HIGH
¥G HIGH
¥B HIGH
¥R LOW
¥G LOW
¥B LOW
¥CONTRAST
¥BRIGHT.
¥R LEVEL
¥G LEVEL
¥B LEVEL
¥H.ENHANCE
¥V.ENHANCE
IN1–PC#1
¥CONTRAST
¥BRIGHT.
¥H.ENHANCE
¥V.ENHANCE
IN1–PC#1 Color mode 1
¥R HIGH
¥G HIGH
¥B LOW
¥CONTRAST
¥BRIGHT.
¥H.ENHANCE
¥V.ENHANCE
IN1–PC#1 Color mode 2
¥R HIGH
¥G HIGH
¥B LOW
INPUT2(PC)
PC#1
PC#2
PC#3
PC#4
PC#5
PC#6
PC#7
PC#8
¥CONTRAST
¥BRIGHT.
¥R LEVEL
¥G LEVEL
¥B LEVEL
¥H.ENHANCE
¥V.ENHANCE
IN2–PC#1
¥CONTRAST
¥BRIGHT.
¥H.ENHANCE
¥V.ENHANCE
IN2–PC#1 Color mode 1
¥R HIGH
¥G HIGH
¥B LOW
¥CONTRAST
¥BRIGHT.
¥H.ENHANCE
¥V.ENHANCE
IN2–PC#1 Color mode 2
¥R HIGH
¥G HIGH
¥B LOW
★: applies only when equipped with PDA-5002)
