91
Plasma Display Ceiling Suspension Hardware: PDK-5012
4.8.2 External Dimensions
7 When using plasma display monitor PDP-503CMX or PDP-503MXE
(Unit: mm)
4-φ13.5X22
80
98
277
(493)
146
40
1157
67
129
(530)
496
300
980
800
1218
200
300
φ70
φ240.5
216
615
R
672
R
45
°
45°
φ60.5
329 100
714
This circle shows the path that the outermost
part of the plasma display follows when it is
rotated about a vertical axis after having been
titled sideways by 25°.
This circle shows the path that the outermost
part of the plasma display follows when it is
rotated about a vertical axis after having been
titled sideways by 25°.
[503CMX/503MXE : 433CMX/433MXE]
Attachment
use holes
(6 locations)
