86
4.7 Wall-mounted type tiltable fixed plasma display hardware PDK-5013
4.7.1 Specifications
External dimensions ................. 1218 (W) × 714 (H) × 130 (D) mm
(47-15/16 (W) × 28-1/8 (H) × 5-1/8 (D) in.)
(when using PDP-503CMX or PDP-503MXE)
1070 (W) × 630 (H) × 130 (D) mm
(42-1/8 (W) × 24-13/16 (H) × 5-1/8 (D) in.)
(when using PDP-433CMX or PDP-433MXE)
Weight ....................................... 8.9 kg (19.6 lbs.) (mounting hardware only)
47.8 kg (105.4 lbs.) (mounting hardware and plasma display monitor <when using
PDP-503CMX or PDP-503MXE>)
40.4 kg (88.2 lbs.) (mounting hardware and plasma display monitor <when using
PDP-433CMX or PDP-433MXE>)
Materials .................................... General structural steel tubes (STK-MR)
Finish.......................................... Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging......... 1070 (W) × 90 (H) 590 (D) × mm
(42-1/8 (W) × 3-17/32 (H) × 23-7/32 (D) in.)
Package weight......................... 12.0 kg
(26.5 lbs.)
Layers of packing ...................... 30 layers
Components
Hung on wall unit ................................................ × 1
Bolt M8 ............................................................... × 6
Hexagonal wrench
(Opposite side 6 mm for M8 use) ....................... × 1
Stencil ................................................................. × 1
In wall-mounting installation allow adequate space (a clearance of 300 mm or more) above and below the monitor set,
as well as on the right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature: 0 to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-5013.
✩ Operating temperature restrictions for when the speaker system (PDP-S05-LR, PDP-S07-LR) is attached.
• Ambient temperature: 0 to 40 °C
Wall-mounted type tiltable fixed plasma display hardware PDK-5013
[503CMX/503MXE : 433CMX/433MXE]
