The contents of “5.1 Before Beginning Adjustments” and subsequent sections are premised on the PDP-503CMX/
PDP-503MXE and PDP-433CMX/PDP-433MXE being equipped with the PDA-5002.
Items that apply only when the PDA-5002 is installed are marked with a star “★”.
When the PAD-5002 is not installed, the PDP-503CMX/PDP-503MXE will not handle the following functions.
Input terminals
INPUT 1,2 Input • Component video signal
• RGB signals from AV devices other than PCs
INPUT 3 Input S terminal (mini DIN 4 PIN connector)
• Y/C separate video signal
Input Pin jacks x 2
• Audio L/R signal
INPUT 4 Input BNC terminal
• Composite video signal
Output BNC terminal
Input Pin jack x 2
• Audio L/R signal
INPUT 5 Input DVI-D 24 pin terminal
• Digital RGB signal
