Plasma Display Ceiling Suspension Hardware: PDK-5012
4.8 Plasma Display Ceiling Suspension Hardware: PDK-5012
4.8.1 Specifications
External dimensions ................. 1218 (W) × 1157 (H) × 300 (D) mm
(47-15/16 (W) × 45-9/16 (H) × 11-13/16 (D) in.)
(when using PDP-503CMX or PDP-503MXE)
1070 (W) × 1073 (H) × 300 (D) mm
(42-1/8 (W) × 42-1/4 (H) × 11-13/16 (D) in.)
(when using PDP-433CMX or PDP-433MXE)
(with plastic display in horizontal position)
Weight ....................................... 14.5 kg (32.0 lbs.) (mounting hardware only)
53.4 kg (117.7 lbs.) (mounting hardware and plasma display monitor <when using
PDP-503CMX or PDP-503MXE>)
45.8 kg (101.01 lbs.) (mounting hardware and plasma display monitor <when using
PDP-433CMX or PDP-433MXE>)
Adjustable range of angles ...... Horizontal to 25 degrees below horizontal, 45 degrees left/right
Material...................................... Steel pipe for general structure (STK-MR)
Finish.......................................... Semi-matte black paint (Original Pioneer color)
Package dimensions ................. 1035 (W) × 360 (H) × 540 (D) mm
(40-3/4 (W) × 14-3/16 (H) × 21-1/4 (D) in.)
Package weight......................... 23.5 kg
(51.8 lbs.)
Layers of packing ...................... 10 layers
Components
PDP bracket ........................................................ × 1
Bolt M8 ............................................................... × 6
Special screw ...................................................... × 4
Stencil (printed on the wrapping
material that is inside) ......................................... × 1
Installer's contact information (Japan only) ......... × 1
Operating instructions ......................................... × 1
The appropriate types of screws and other mounting hardware will depend on the strength and composition of the
ceiling. Prepare them separately.
✩ Operating Temperature Restrictions
• Ambient Temperature: 0 to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
• Ambient temperature: 0 to 40 °C
• Other factors: Maintain sufficient clearance between the display and the wall (at least 300 mm)
✩ Operating temperature restrictions for when the speaker system (PDP-S05-LR, PDP-S07-LR) is attached.
• Ambient temperature: 0 to 40 °C
[503CMX/503MXE : 433CMX/433MXE]
