BODY / STEERING / S USPENSION
5.5
SIDE PANEL REMOVAL
Side panel removal may be difficult until the locking
tabs and receivers have been snapped and un-
snapped a few times.
1. Removeseat. Grasprearofsidepanelnearrear
cab. With aquick andfirm motion, pull thepanel
forward and outward to disengage the two rear
tabs.
2. Place hand on top of side panel behind the fuel
tank. With a quick and firm motion, push down
on the side panel to disengage the top rear two
tabs. Then pull up on side panel to disengage
front upper and lower tab.
3. To reinstall side panel, align panel tabs with slots on
front cab. Push panel upward and forward untiltabs
lock. Bend rear of side paneland insert the twotabs
into the rear cab.
Pull forward and out to disengage
two rear tabs.
Step 1.
Push down to disengage top rear
two tabs.
Step 2.
To reinstall, align panel tabs with
slots. Push upward and forward
until tabs lock.
Step 3.
