BRAKES
9.21
FRONT CALIPER INSTALLATION
1. Install caliper on hub strut, and torque mounting bolts.
2. Install brake line and tighten securely with a line
wrench.
3. Install the adjuster screw and turn until stationary pad
contacts disc, then back off 1/2 turn.
4. Follow brake bleeding procedure outlined on pages
9.7-9.8.
5. Install wheels and torque wheel nuts to specification.
NOTE: If new brake pads are installed, it is recommended
thataburnishingprocedurebeperformedtoextendpadser-
vice life and reduce noise. Start machine and slowly in-
creasespeedto30mph.Graduallyapplybrakestostopma-
chine. Repeat procedure 10 times.
Front Caliper Mounting Bolt Torque
18 ft. lbs. (25 Nm)
Front Wheel Nut Torque
20 ft. lbs. (27 Nm).
