Device Search Software
135
A.2. Device Search Software
A.2.1 Initial Camera Configuration
To perform the initial camera configuration:
1. Unpack the camera. Rotate and remove the protective cover.
2. Remove the PE cloth sheet and lens cap. Attach the dome cover to the body.
3. Insert the RJ45 plug at the end of the network cable into the network port of the camera.
4. Do one of the following:
o Copy and run the devicesearch.exe from the included CD.
Device Search is an alternative software to DNA. Either of these programs
may be used. Both are supplied on the included CD.
o From the Latitude Sidebar, run the Unified Configurator by selecting Applications >
Device Configuration Tool and then on the Unified Configurator screen, click DVTEL
HD Series.
5. In the Device Search application, click Device Search and do the following:
a. In the search results, click on the camera to select it.
b. Right-click and select from the shortcut menu Network Setup.
Figure 113: Device Search Application
c. In the dialog that appears, select Static IP.
d. Enter the IP Address, Gateway and Netmask (network mask) as needed and click OK.
6. Disconnect the Ethernet cable. The camera is ready for deployment in a site installation
(mounting).
The camera can be connected to a PC for bench installation via an Ethernet
cross-cable.
The camera default IP Address and the subnet mask IP Address are automatically
supplied by the DHCP server.
