Quasar CP-3211 User Manual

Installation
23
11. Screw the supplied M5 standard screw/security screw as shown in the figure below.
Figure 8: Ceiling Mounting: Straight Tube + Mount Kit
Swan Tube Mounting (Roof Mount)
Items needed:
 Indoor pendant mount kit or outdoor mount kit (standard with outdoor cameras)
 Swan tube mount package (DVTEL camera mounting option available separately)
 Screws and screw anchors for fixing the swan tube onto the floor (not provided)
Swan tube mounting package contents:
 M8x12 screw x1
 Spring washer 8 x1
 Pendant tube washer x1
 Waterproof rubber gasket x1

Quasar CP-3211 Specifications

General

Brand	Quasar
Model	CP-3211
Category	Security Camera
Language	English
