Quasar CP-3211/CP-4221 User and Installation Guide
32
5.6.4 Pole Mount
There are two methods for pole-mounting a camera:
 Pole Thin/Wide Direct Mounting
 Pole Thin/Wide Box Mounting
Pole Thin/Wide Direct Mounting
The pole thin/wide direct mount must be used in conjunction with the standard or compact wall
mount.
Items needed:
 Indoor pendant mount kit or outdoor mount kit (standard with outdoor cameras).
 Standard/compact wall mount package (DVTEL camera mounting option available
separately).
 Pole thin/wide direct mount package (DVTEL camera mounting option available
separately).
Pole thin/wide direct mounting package contents:
 Stainless steel straps x4
 M8x16 screw x4
 Spring washer 8 x4
 Washer x4
 Sponge x2
Tools required:
 Stainless steel strap cutter
 Phillips and flat-head screwdrivers
To install the standard/compact wall mount with pole thin/wide direct mount:
1. Fasten the pole thin/wide direct mount to a pole with the supplied stainless straps.
2. Thread the cables through the pole thin/wide direct mount.
3. Attach the standard/compact wall mount to the pole thin/wide direct mount using the
supplied screws and washers.
4. Thread the cables through the standard/compact wall mount with the cables coming out of
the pendant mount’s outlet. For outdoor cameras, attach the waterproof gasket to the
pendant mount.
5. After threading the cables, block the entry hole with the supplied sponge to prevent insects
from entering. See Standard or Compact Wall Mount, Step 3.
6. Thread the cables through the indoor or outdoor mount kit and attach the mount kit to the
standard/compact wall mount using the supplied screws and washers.
7. For outdoor cameras, adjust the waterproof gasket to the joint.
8. Connect the cables to the camera.
9. Secure the camera to the indoor or outdoor mount kit.
