Technical Bulletin PAGE: 2/2
Model: CH-C1
Date: 16-Oct-13
No.: RD135039
3. Insert the Toner Shield Glass Cleaning Tool [A] into the slot [B], and slide it back-and-
forth about 5 times to clean the toner shield glass on the laser units. Do this procedure
for all 4 colors.
Pg. 39 of Appendices
The following cleaning items were added to the Mainframe PM table.
[A]
Y
M
C
K
[B]
Laser Unit
Toner Shield Glass
Toner Shield Glass
Cleaning Tool
