Technical Bulletin PAGE: 1/3

Model:

CH-C1

Date:

19-Feb-19

No.:

RD135180

Subject: SC525-01

Lock bracket is broken

Prepared by:

K. Yamamoto

From: Field Quality Management Group1, FQM Dept.

Classification:

Troubleshooting

Mechanical

Paper path

Part information

Electrical

Transmit/receive

Action required

Service manual revision

Retrofit information

Product Safety Other ( ) Tier 2

SYMPTOM

SC525-01 is triggered and the drawer unit does not open.

CAUSE

The lock bracket breaks.
