Technical Bulletin PAGE: 1/2
Model: Model CH-C1
Date: 6-Nov-13
No.: RD135042
Action required in the field:
1. Pull out the tandem tray.
2. Unlock the hook [A] and remove the tray front cover [B]. ( x 2)
3. Push the right tandem tray into the machine.
4. Push the left tray and set the bracket [A] by adjusting the two screws so that the end of the bracket [A]
just comes into contact with the right tandem tray when the left tray is fully pushed in.
[A]
[B]
[A]
