Technical Bulletin PAGE: 2/2
Model: CH-C1 Office/Pro
Date: 26-May-14
No.: RD135119
SC No.
Level
Error Name/Error Condition/Major Cause/Solution
In Vd detection, which is done at the beginning of process
control, the measured potential (Vd) is converted to the
potential when -700 V is applied to the drum (Vd700) and
used to check the potential sensor.
 Potential sensor probe connector disconnected
 Potential sensor probe defective
 Disconnect and reconnect the harness connecting the
IOB and potential sensor board, then check the sensor
again.
 If this does not solve the problem, replace the potential
sensor probe.
