Technical Bulletin PAGE: 4/4

Model: CH-C1

Date: 26-Mar-14

No: RD135128

3. Remove the sensor bracket. ( X 4)

4. Attach the spacer to the side plate located in the rear side of the mainframe as shown

below.

Mainframe rear

side plate

Tolerance: Within

2mm from the

center of the screw

hole

Tolerance: Within 3mm

from the bottom edge

of the screw hole

Enlarged view

Attach the

spacer to the

area outlined in

red.
