Technical Bulletin PAGE: 17/17
Reissued:4-Jul-14
Model: CH-C1
Date: 19-Jun-14
No: RD135136a
31. Attach the decal to both right and left slide rails, if you are working on a D137/D138 model
NOTE
Discard the decal if the machine you are working on is a D135/D136 model.
CASE 2: There is a noticeable gap/clearance between the outer slide and release
lever.
1. Do the same as in STEPS #1–21 for Case 1, but have another technician holding the left side
of drawer unit (as shown in the photos in Step 11). This is to prevent the drawer unit from
falling.
2. Do the same as in STEP #22-31.
