Technical Bulletin PAGE: 2/3
Reissued: 21-Nov-17
Model: CH-C1
Date: 12-Jul-16
No.: RD135166a
Change/Reason:
Standardization with C-2 models, lower risk of generating noise
(*)To facilitate servicing and parts standardization with the C2 model, Heat Roller
Core Assembly was registered as a spare part, which is one of the components of
the Heat Roller assembly.
The shape of the Feeler Turn Shaft Bracket was changed. The interchangeability
between the old and new parts is X/X although the 201611 PCIL had falsely
mentioned O/O.
D2584468
CORE:HEAT
ROLLER:ASS'Y
D2584460
HEAT ROLLER:ASS'Y
D1364231  D2584321
BRACKET:SHAFT:TURN:FEELER
