7
1. Placing Originals
This chapter describes the types of originals you can set and how to place originals.
Originals
This section describes the types of originals that can be placed, paper sizes that
are automatically detected, and missing image area.
Sizes and Weights of Recommended Originals
The following describes recommended paper sizes and weights, and non-rec-
ommended originals for the ADF or ARDF.
❖ Metric version
❖ Inch version
*
The optional ARDF is required.
Note
❒ About 30 originals can be placed in the ADF.
❒ About 50 originals can be placed in the ARDF.
Where original is
placed Original size Original weight
Exposure glass Up to A3 --
ADF / ARDF One-sided originals:
A3L – A5KL
ADF: 52-105 g/m
2
ARDF: 40-128 g/m
2
Two-sided originals:
*
A3L – A5KL
64–105 g/m
2
*
Where original is
placed Original size Original weight
Exposure glass Up to 11" × 17" --
ADF / ARDF One-sided originals:
11" × 17"L – 5
1
/
2
" × 8
1
/
2
"KL
ADF: 14-28 lb.
ARDF: 10-34 lb.
Two-sided originals:
*
11" × 17"L – 5
1
/
2
" × 8
1
/
2
"KL
17–28 lb.
*
