1. Connecting the Machine
This chapter describes how to connect the machine to the network and specify
the network settings.
Connecting to the Interfaces
This section explains how to identify the machine’s interface and connect the
machine according to the network environment.
1. USB port
Port for connecting the USB 2.0 cable
2. 10BASE-T/100BASE-TX port
Port for connecting the 10BASE-T or
100BASE-TX cable
3. IEEE 1284 port (optional)
Port for connecting the IEEE 1284 inter-
face cable
4. IEEE 802.11b (Wireless LAN) port
(optional)
Port for using the wireless LAN
Note
! You cannot install two or more of the options below: IEEE 802.11b wireless
LAN board, IEEE 1284 interface board.
ARG003S
