Commissioning via the built-in BOP
5.6 Function commissioning
SINAMICS V20 Converter
Operating Instructions, 10/2019, A5E34559884-012
109
5.6.3 Commissioning advanced functions
5.6.3.1 Starting the motor in super torque mode
Functionality
This startup mode applies a torque pulse for a given time to help start the motor.
Typical application field
Sticky pumps
Setting parameters
P3350[0...2] Super torque modes = 1: Enable super torque mode
When the value of P3350 is changed, the value of P3353 is
changed as follows:
• P3350 = 2: P3353 = 0.0s
• P3350 ≠ 2: P3353 = default
The ramp time of 0s gives an additional 'kicking' effect when hammer
P3351[0...2] BI: Super torque enable This parameter defines the source of the super torque enable. The set-
ting is effective when P3352 = 2.
Factory default: 0 (never enabled)
P3352[0...2] Super torque startup mode This parameter defines when the super torque function becomes active.
= 0: Enabled on first run after power-up
= 1: Enabled on every run
= 2: Enabled by digital input (enable source is defined by P3351; 0 =
never enabled, 1 = enabled on every run)
P3353[0...2] Super torque ramp time [s] This parameter defines the ramp time to be used when ramping up to
the super torque frequency.
Range: 0.0 to 650.0 (factory default: 5.0)
P3354[0...2] Super torque frequency [Hz] This parameter defines the frequency at which the additional boost is
applied for super torque mode.
Range: 0.0 to 550.0 (factory default: 5.0)
P3355[0...2] Super torque boost level [%] This parameter sets the temporary boost level for super torque mode.
It applies boost in [%] relative to P0305 (rated motor current) once the
super torque frequency has been reached for the time specified in
P3356.
Range: 0.0 to 200.0 (factory default: 150.0)
P3356[0...2] Super torque boost time [s] This parameter sets the time for which the additional boost is applied,
when the output frequency is held at P3354.
Range: 0.0 to 20.0 (factory default: 5.0)
