B.1.6 Output reactor
CAUTION
Pulse frequency restriction
The output reactor works only at 4kHz switching frequency. Before the output reactor is
used, parameters P1800 and P0290 must be modified as follows: P1800 = 4 and P0290 =
0 or 1.
Functionality
The output reactor reduces the voltage stress on the motor windings. At the same time, the
capacitive charging/discharging currents, which place an additional load on the converter
output when long motor cables are used, are reduced.
For safety reasons, it is recommended to use a shielded cable (maximum length: 200 m) to
connect the output reactor. When the output reactor is used, the output frequency of the
converter must be no more than 150 Hz.
Note that the output reactors comply with degree of protection of IP20.
Ordering data
Frame size
Converter power rating
Output reactor
Article number
Voltage
Current
Three phase AC 400 V converters
FSA
0.37 kW
6SL3202-0AE16-1CA0 380 V to 480 V 6.1 A
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
6SL3202-0AE18-8CA0 380 V to 480 V 9.0 A
FSB
3 kW
4 kW
6SL3202-0AE21-8CA0 380 V to 480 V 18.5 A
FSC
5.5 kW
FSD
7.5 kW
6SL3202-0AE23-8CA0 380 V to 480 V 39.0 A
11 kW
15 kW
FSE
18.5 kW
6SE6400-3TC03-8DD0
380 V to 480 V
45.0 A
22 kW
6SE6400-3TC05-4DD0
380 V to 480 V
68.0 A

Siemens SINAMICS V20 Specifications

General

Power Range	0.12 kW to 30 kW
Overload Capacity	150% for 60 seconds
Protection Class	IP20
Storage Temperature Range	-40°C to +70°C
Altitude	Up to 1000 m without derating
Input Voltage	3AC 380 V to 480 V
Output Voltage	0 V to Input Voltage
Control Modes	V/f control
Ambient Temperature Range	-10°C to +60°C
Relative Humidity	5% to 95%, non-condensing
Communication Interfaces	Modbus RTU
Braking Resistor	Optional external
