Commissioning via the built-in BOP
5.5 Quick commissioning
SINAMICS V20 Converter
Operating Instructions, 10/2019, A5E34559884-012
77
MODBUS address for converter
P2022[0] MODBUS reply timeout 1000 1000 Maximum time to send reply back to the
USS/MODBUS telegram off time
Parity of MODBUS telegrams on RS485
P2035 MODBUS stop bits on RS485 1 1 Number of stop bits in MODBUS tele-
5.5.1.4 Setting application macros
Application macro settings
When commissioning the converter, the application macro setting is a one-off setting. Make
sure that you proceed as follows before yo
u change the application macro setting to a value
different from your last setting:
1. Do a factory reset (P0010 = 30, P0970 = 1)
2. Repeat the quick commissioning and change the application macro
Failure to observe may cause the converter to accept the parameter settings from both the
currently and the previously selected macros, which may lead to undefined and
unexplainable operation.
Functionality
This menu defines certain common applications. Each application macro provides a set of
parameter settings for a specific application. After you select an application macro, the
corresponding settings are applied to the converter to simplify the commissioning process.
The default application macro is "AP000" for application macro 0. If none of the application
macros fits your application, select the one that is the closest to your application and make
further parameter changes as desired.
Factory default setting. Makes no parameter changes.
The minus sign indicates that this macro is
the currently selected macro.
AP030 Conveyor applications
