2 Functions
104
7SD5 Manual
C53000-G1176-C169-1
2.3.4 Information List
No. Information Type of In-
formation
Comments
3101 IC comp. active OUT IC compensation active
3102 2nd Harmonic L1 OUT Diff: 2nd Harmonic detected in phase L1
3103 2nd Harmonic L2 OUT Diff: 2nd Harmonic detected in phase L2
3104 2nd Harmonic L3 OUT Diff: 2nd Harmonic detected in phase L3
3120 Diff active OUT Diff: Active
3132 Diff. Gen. Flt. OUT Diff: Fault detection
3133 Diff. Flt. L1 OUT Diff: Fault detection in phase L1
3134 Diff. Flt. L2 OUT Diff: Fault detection in phase L2
3135 Diff. Flt. L3 OUT Diff: Fault detection in phase L3
3136 Diff. Flt. E OUT Diff: Earth fault detection
3137 I-Diff>> Flt. OUT Diff: Fault detection of I-Diff>>
3139 I-Diff> Flt. OUT Diff: Fault detection of I-Diff>
3141 Diff. Gen. TRIP OUT Diff: General TRIP
3142 Diff TRIP 1p L1 OUT Diff: TRIP - Only L1
3143 Diff TRIP 1p L2 OUT Diff: TRIP - Only L2
3144 Diff TRIP 1p L3 OUT Diff: TRIP - Only L3
3145 Diff TRIP L123 OUT Diff: TRIP L123
3146 Diff TRIP 1pole OUT Diff: TRIP 1pole
3147 Diff TRIP 3pole OUT Diff: TRIP 3pole
3148 Diff block OUT Diff: Differential protection is blocked
3149 Diff OFF OUT Diff: Diff. protection is switched off
3176 Diff Flt. 1p.L1 OUT Diff: Fault detection L1 (only)
3177 Diff Flt. L1E OUT Diff: Fault detection L1E
3178 Diff Flt. 1p.L2 OUT Diff: Fault detection L2 (only)
3179 Diff Flt. L2E OUT Diff: Fault detection L2E
3180 Diff Flt. L12 OUT Diff: Fault detection L12
3181 Diff Flt. L12E OUT Diff: Fault detection L12E
3182 Diff Flt. 1p.L3 OUT Diff: Fault detection L3 (only)
3183 Diff Flt. L3E OUT Diff: Fault detection L3E
3184 Diff Flt. L31 OUT Diff: Fault detection L31
3185 Diff Flt. L31E OUT Diff: Fault detection L31E
3186 Diff Flt. L23 OUT Diff: Fault detection L23
3187 Diff Flt. L23E OUT Diff: Fault detection L23E
3188 Diff Flt. L123 OUT Diff: Fault detection L123
3189 Diff Flt. L123E OUT Diff: Fault detection L123E
3190 Test Diff. IntSP Diff: Set Teststate of Diff. protection
3191 Comm. Diff IntSP Diff: Set Commissioning state of Diff.
3192 TestDiff.remote OUT Diff: Remote relay in Teststate
3193 Comm.Diff act. OUT Diff: Commissioning state is active
3194 >Test Diff. SP Diff: >Test Diff.
3195 >Comm. Diff SP Diff: >Comm. Diff
3525 > Diff block SP >Differential protection blocking signal
3526 Diffblk.rec PI1 OUT Differential blocking received at PI1
3527 Diffblk.rec PI2 OUT Differential blocking received at PI2
