2.11 Direct Local Trip
261
7SD5 Manual
C53000-G1176-C169-1
2.11.2 Setting Notes
General A precondition for the direct local trip is that the configuration of the functions (Section
2.1.1) has been configured in address 122 DTT Direct Trip = Enabled. At
address 2201 FCT Direct Trip it can also be switched ON or OFF.
For direct local trip, a trip time delay can be set in address 2202 Trip Time DELAY.
This delay can be used as a grading margin.
Once a trip command has been issued, it is maintained for at least as long as the set
minimum trip command duration TMin TRIP CMD which was set for the device in
general in address 240 (Section 2.1.2). Reliable operation of the circuit breaker is
therefore ensured, even if the initiating signal pulse is very short.
2.11.3 Settings
2.11.4 Information List
Addr. Parameter Setting Options Default Setting Comments
2201 FCT Direct Trip ON
OFF
OFF Direct Transfer Trip (DTT)
2202 Trip Time DELAY 0.00 .. 30.00 sec; ∞ 0.01 sec Trip Time Delay
No. Information Type of In-
formation
Comments
4403 >BLOCK DTT SP >BLOCK Direct Transfer Trip function
4412 >DTT Trip L1 SP >Direct Transfer Trip INPUT Phase L1
4413 >DTT Trip L2 SP >Direct Transfer Trip INPUT Phase L2
4414 >DTT Trip L3 SP >Direct Transfer Trip INPUT Phase L3
4417 >DTT Trip L123 SP >Direct Transfer Trip INPUT 3ph L123
4421 DTT OFF OUT Direct Transfer Trip is switched OFF
4422 DTT BLOCK OUT Direct Transfer Trip is BLOCKED
4432 DTT TRIP 1p. L1 OUT DTT TRIP command - Only L1
4433 DTT TRIP 1p. L2 OUT DTT TRIP command - Only L2
4434 DTT TRIP 1p. L3 OUT DTT TRIP command - Only L3
4435 DTT TRIP L123 OUT DTT TRIP command L123
