4 Technical Data
530
7SD5 Manual
C53000-G1176-C169-1
4.1.9 Certifications
4.1.10 Mechanical Design
UL Listed UL Recognition
7SD5***-*A***-****
Models with threaded termi-
nals
7SD5***-*J***-****
Models with plug-in termi-
nals
7SD5***-*C***-**** 7SD5***-*L***-****
7SD5***-*D***-**** 7SD5***-*M***-****
Housing 7XP20
Dimensions See dimensional drawings, Section 4.25
Device (for maximum number of components) Size Weight
In flush mounting housing
1
/
2
6 kg (13.23 lb)
1
/
1
10 kg (22.04 lb)
In panel surface mounting housing
1
/
2
11 kg (24.24 lb)
1
/
1
19 kg (41.88 lb)
Degree of protection according to IEC 60529
For equipment in surface mounting housing IP 51
For equipment in flush mounting housing
Front IP 51
Back IP 50
For human safety IP 2x with cover cap
UL-certification conditions „For use on a Flat Surface of a Type 1 Enclosure“
