2 Functions
248
7SD5 Manual
C53000-G1176-C169-1
2.9.8 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
2.9.9 Information List
Addr. Parameter Setting Options Default Setting Comments
3201 FCT Telep. E/F ON
OFF
ON Teleprotection for Earth Fault O/C
3202 Line Config. Two Terminals
Three terminals
Two Terminals Line Configuration
3203A Send Prolong. 0.00 .. 30.00 sec 0.05 sec Time for send signal prolongation
3207A Delay for alarm 0.00 .. 30.00 sec 10.00 sec Unblocking: Time Delay for Alarm
3208 Release Delay 0.000 .. 30.000 sec 0.000 sec Time Delay for release after
pickup
3209A TrBlk Wait Time 0.00 .. 30.00 sec; ∞ 0.04 sec Transient Block.: Duration exter-
nal flt.
3210A TrBlk BlockTime 0.00 .. 30.00 sec 0.05 sec Transient Block.: Blk.T. after ext.
flt.
No. Information Type of In-
formation
Comments
1311 >EF Teleprot.ON SP >E/F Teleprotection ON
1312 >EF TeleprotOFF SP >E/F Teleprotection OFF
1313 >EF TeleprotBLK SP >E/F Teleprotection BLOCK
1318 >EF Rec.Ch1 SP >E/F Carrier RECEPTION, Channel 1
1319 >EF Rec.Ch2 SP >E/F Carrier RECEPTION, Channel 2
1320 >EF UB ub 1 SP >E/F Unblocking: UNBLOCK, Channel 1
1321 >EF UB bl 1 SP >E/F Unblocking: BLOCK, Channel 1
1322 >EF UB ub 2 SP >E/F Unblocking: UNBLOCK, Channel 2
1323 >EF UB bl 2 SP >E/F Unblocking: BLOCK, Channel 2
1324 >EF BlkEcho SP >E/F BLOCK Echo Signal
1325 >EF Rec.Ch1 L1 SP >E/F Carrier RECEPTION, Channel 1, Ph.L1
1326 >EF Rec.Ch1 L2 SP >E/F Carrier RECEPTION, Channel 1, Ph.L2
1327 >EF Rec.Ch1 L3 SP >E/F Carrier RECEPTION, Channel 1, Ph.L3
1328 >EF UB ub 1-L1 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L1
1329 >EF UB ub 1-L2 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L2
1330 >EF UB ub 1-L3 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L3
1371 EF Tele SEND L1 OUT E/F Telep. Carrier SEND signal, Phase L1
1372 EF Tele SEND L2 OUT E/F Telep. Carrier SEND signal, Phase L2
1373 EF Tele SEND L3 OUT E/F Telep. Carrier SEND signal, Phase L3
1374 EF Tele STOP L1 OUT E/F Telep. Block: carrier STOP signal L1
1375 EF Tele STOP L2 OUT E/F Telep. Block: carrier STOP signal L2
1376 EF Tele STOP L3 OUT E/F Telep. Block: carrier STOP signal L3
1380 EF TeleON/offBI IntSP E/F Teleprot. ON/OFF via BI
1381 EF Telep. OFF OUT E/F Teleprotection is switched OFF
