2.16 Synchronism and Voltage Check (optional)
323
7SD5 Manual
C53000-G1176-C169-1
2.16.4 Information List
3515A SYNC-CHECK YES
NO
YES Live bus / live line and Sync
before AR
3516 Usync> U-line< YES
NO
NO Live bus / dead line check before
AR
3517 Usync< U-line> YES
NO
NO Dead bus / live line check before
AR
3518 Usync< U-line< YES
NO
NO Dead bus / dead line check before
AR
3519 OVERRIDE YES
NO
NO Override of any check before AR
3530 Op.mode with MC with T-CB close
w/o T-CB close
w/o T-CB close Operating mode with Man.Cl
3531 MC maxVolt.Diff 1.0 .. 40.0 V 2.0 V Maximum voltage difference
3532 MC maxFreq.Diff 0.03 .. 2.00 Hz 0.10 Hz Maximum frequency difference
3533 MC maxAngleDiff 2 .. 80 ° 10 ° Maximum angle difference
3535A MC SYNCHR YES
NO
YES Live bus / live line and Sync
before MC
3536 MC Usyn> Uline< YES
NO
NO Live bus / dead line check before
Man.Cl
3537 MC Usyn< Uline> YES
NO
NO Dead bus / live line check before
Man.Cl
3538 MC Usyn< Uline< YES
NO
NO Dead bus / dead line check before
Man.Cl
3539 MC O/RIDE YES
NO
NO Override of any check before
Man.Cl
No. Information Type of In-
formation
Comments
2901 >Sync. on SP >Switch on synchro-check function
2902 >Sync. off SP >Switch off synchro-check function
2903 >BLOCK Sync. SP >BLOCK synchro-check function
2905 >Sync. Start MC SP >Start synchro-check for Manual Close
2906 >Sync. Start AR SP >Start synchro-check for AR
2907 >Sync. synch SP >Sync-Prog. Live bus / live line / Sync
2908 > Usyn< U-line> SP >Sync-Prog. Dead bus / live line
2909 > Usyn> U-line< SP >Sync-Prog. Live bus / dead line
2910 > Usyn< U-line< SP >Sync-Prog. Dead bus / dead line
2911 >Sync. o/ride SP >Sync-Prog. Override ( bypass )
2930 Sync. on/off BI IntSP Synchro-check ON/OFF via BI
2931 Sync. OFF OUT Synchro-check is switched OFF
2932 Sync. BLOCK OUT Synchro-check is BLOCKED
2934 Sync. faulty OUT Synchro-check function faulty
2935 Sync.Tsup.Exp OUT Synchro-check supervision time expired
Addr. Parameter Setting Options Default Setting Comments
