Siemens siprotec 7SD5 User Manual

2 Functions
340
7SD5 Manual
C53000-G1176-C169-1
2.17.5 Information List
No. Information Type of In-
formation
Comments
10201 >Uph-e>(>) BLK SP >BLOCK Uph-e>(>) Overvolt. (phase-earth)
10202 >Uph-ph>(>) BLK SP >BLOCK Uph-ph>(>) Overvolt (phase-phase)
10203 >3U0>(>) BLK SP >BLOCK 3U0>(>) Overvolt. (zero sequence)
10204 >U1>(>) BLK SP >BLOCK U1>(>) Overvolt. (positive seq.)
10205 >U2>(>) BLK SP >BLOCK U2>(>) Overvolt. (negative seq.)
10206 >Uph-e<(<) BLK SP >BLOCK Uph-e<(<) Undervolt (phase-earth)
10207 >Uphph<(<) BLK SP >BLOCK Uphph<(<) Undervolt (phase-phase)
10208 >U1<(<) BLK SP >BLOCK U1<(<) Undervolt (positive seq.)
10215 Uph-e>(>) OFF OUT Uph-e>(>) Overvolt. is switched OFF
10216 Uph-e>(>) BLK OUT Uph-e>(>) Overvolt. is BLOCKED
10217 Uph-ph>(>) OFF OUT Uph-ph>(>) Overvolt. is switched OFF
10218 Uph-ph>(>) BLK OUT Uph-ph>(>) Overvolt. is BLOCKED
10219 3U0>(>) OFF OUT 3U0>(>) Overvolt. is switched OFF
10220 3U0>(>) BLK OUT 3U0>(>) Overvolt. is BLOCKED
10221 U1>(>) OFF OUT U1>(>) Overvolt. is switched OFF
10222 U1>(>) BLK OUT U1>(>) Overvolt. is BLOCKED
10223 U2>(>) OFF OUT U2>(>) Overvolt. is switched OFF
10224 U2>(>) BLK OUT U2>(>) Overvolt. is BLOCKED
10225 Uph-e<(<) OFF OUT Uph-e<(<) Undervolt. is switched OFF
10226 Uph-e<(<) BLK OUT Uph-e<(<) Undervolt. is BLOCKED
10227 Uph-ph<(<) OFF OUT Uph-ph<(<) Undervolt. is switched OFF
10228 Uph-ph<(<) BLK OUT Uphph<(<) Undervolt. is BLOCKED
10229 U1<(<) OFF OUT U1<(<) Undervolt. is switched OFF
10230 U1<(<) BLK OUT U1<(<) Undervolt. is BLOCKED
10231 U</> ACTIVE OUT Over-/Under-Voltage protection is ACTIVE
10240 Uph-e> Pickup OUT Uph-e> Pickup
10241 Uph-e>> Pickup OUT Uph-e>> Pickup
10242 Uph-e>(>) PU L1 OUT Uph-e>(>) Pickup L1
10243 Uph-e>(>) PU L2 OUT Uph-e>(>) Pickup L2
10244 Uph-e>(>) PU L3 OUT Uph-e>(>) Pickup L3
10245 Uph-e> TimeOut OUT Uph-e> TimeOut
10246 Uph-e>> TimeOut OUT Uph-e>> TimeOut
10247 Uph-e>(>) TRIP OUT Uph-e>(>) TRIP command
10255 Uphph> Pickup OUT Uph-ph> Pickup
10256 Uphph>> Pickup OUT Uph-ph>> Pickup
10257 Uphph>(>)PU L12 OUT Uph-ph>(>) Pickup L1-L2
10258 Uphph>(>)PU L23 OUT Uph-ph>(>) Pickup L2-L3
10259 Uphph>(>)PU L31 OUT Uph-ph>(>) Pickup L3-L1
10260 Uphph> TimeOut OUT Uph-ph> TimeOut
10261 Uphph>> TimeOut OUT Uph-ph>> TimeOut
10262 Uphph>(>) TRIP OUT Uph-ph>(>) TRIP command
10270 3U0> Pickup OUT 3U0> Pickup
10271 3U0>> Pickup OUT 3U0>> Pickup
10272 3U0> TimeOut OUT 3U0> TimeOut
