2 Functions
388
7SD5 Manual
C53000-G1176-C169-1
1)
After three unsuccessful restarts, the device is taken out of service.
2)
DOK = „Device OK“ = Break contact of the readiness relay = Life contact
2.22.1.5 Setting Notes
General The sensitivity of the measurement supervision function can be modified. Default
values are set at the factory, which are sufficient in most cases. If especially high op-
erating asymmetry in the currents and/or voltages is to be expected for the application,
or if it becomes apparent during operation that certain monitoring functions activate
sporadically, then the setting should be less sensitive.
The measurement supervision can be switched ON or OFF in address 2901
MEASURE. SUPERV.
Voltage failure, three-
phase „Fuse-Failure-
Monitor“
External (power system or
connection)
Indication
Distance protection is
blocked,
Undervoltage protection
is blocked,
Weak-infeed tripping is
blocked,
Frequency protection is
blocked, and
Direction determination
of the earth fault protec-
tion is blocked
„VT FuseFail>10s“
(169),
„VT FuseFail“ (170)
As allocated
Voltage failure, single
and two-phase „Fuse-
Failure-Monitor“
External (voltage transform-
ers)
Indication
Distance protection is
blocked,
Undervoltage protection
is blocked,
Weak-infeed tripping is
blocked,
Frequency protection is
blocked, and
Direction determination
of the earth fault protec-
tion is blocked
„VT FuseFail>10s“
(169),
„VT FuseFail“ (170)
As allocated
Voltage failure, three-
phase
External (power system or
connection)
Indication
Distance protection is
blocked,
Undervoltage protection
is blocked,
Weak-infeed tripping is
blocked,
Frequency protection is
blocked, and
Direction determination
of the earth fault protec-
tion is blocked
„Fail U absent“ (168) As allocated
Trip circuit supervision External (trip circuit or
control voltage)
Indication „FAIL: Trip cir.“
(6865)
As allocated
Monitoring Possible causes Malfunction Re-
sponse
Indication (No.) Device
