Siemens siprotec 7SD5 User Manual

A Appendix
616
7SD5 Manual
C53000-G1176-C169-1
A.5 Protocol-dependent Functions
Protocol → IEC 60870-5-103 Profibus FMS Profibus DP DNP 3.0
Function ↓
Operational Mea-
sured Values
Yes Yes Yes Yes
Metered Values Yes Yes Yes Yes
Fault Recording Yes Yes No No
Remote Relay
Setting
User-defined
Alarms and Switch-
ing Objects
Yes Yes Predefined „User-
defined Alarms“ in
CFC
Predefined „User-
defined Alarms“ in
CFC
Time Synchroniza-
tion
Via protocol;
DCF77/IRIG B/GPS;
Interface;
Binary Input
Via protocol;
DCF77/IRIG B/GPS;
Interface;
Binary Input
Via DCF77/IRIG
B/GPS;
Interface;
Binary Input
Via protocol;
DCF77/IRIG B/GPS;
Interface;
Binary Input
Messages with Time
Stamp
Yes Yes No Yes
Commissioning Tools
Alarm and Mea-
sured Value Trans-
mission Blocking
Yes Yes No No
Generate Test
Alarms
Yes Yes No No
Physical Mode Asynchronous Asynchronous Asynchronous Asynchronous
Transmission Mode Cyclic/Event Cyclic/Event Cyclic Cyclic/Event
Baud Rate 4800 to 38400 up to 1.5 Mbaud up to 1.5 Mbaud 2400 to 19200
Type RS232/RS485
Fibre-optic cables
RS485
Fibre-optic cables
Double ring
RS485
Fibre-optic cables
Double ring
RS485
Fibre-optic cables
