2 Functions
430
7SD5 Manual
C53000-G1176-C169-1
The data can be retrieved via the serial interfaces by means of a personal computer
and evaluated with the operating software DIGSI
®
and the graphic analysis software
SIGRA 4. The latter graphically represents the data recorded during the system fault
and also calculates additional information from the measured values. A selection may
be made as to whether the measured quantities are represented as primary or sec-
ondary values. Binary signal traces (marks) of particular events, e.g. „fault detection“,
„tripping“ are also represented.
If the device has a serial system interface, the fault recording data can be passed on
to a central device via this interface. The data is evaluated by applicable programs in
the central device. The measured quantities are referred to their maximum values,
scaled to their rated values and prepared for graphic representation. Binary signal
traces (marks) of particular events, e.g. „fault detection“, „tripping“ are also represent-
ed.
Where transfer to a central device is possible, the request for data transfer can be ex-
ecuted automatically. It can be selected to take place after each fault detection by the
protection, or only after a trip.
2.24.8.2 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Ad-
ditional Settings.
2.24.8.3 Information List
Addr. Parameter Setting Options Default Setting Comments
402A WAVEFORMTRIGGE
R
Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
403A WAVEFORM DATA Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
410 MAX. LENGTH 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
411 PRE. TRIG. TIME 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
412 POST REC. TIME 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
415 BinIn CAPT.TIME 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
No. Information Type of In-
formation
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
203 Wave. deleted OUT_Ev Waveform data deleted
