2.10 Weak-infeed Tripping (optional)
259
7SD5 Manual
C53000-G1176-C169-1
4233 W/I Pickup L2 OUT Weak Infeed PICKUP L2
4234 W/I Pickup L3 OUT Weak Infeed PICKUP L3
4241 WeakInfeed TRIP OUT Weak Infeed General TRIP command
4242 Weak TRIP 1p.L1 OUT Weak Infeed TRIP command - Only L1
4243 Weak TRIP 1p.L2 OUT Weak Infeed TRIP command - Only L2
4244 Weak TRIP 1p.L3 OUT Weak Infeed TRIP command - Only L3
4245 Weak TRIP L123 OUT Weak Infeed TRIP command L123
4246 ECHO SIGNAL OUT ECHO Send SIGNAL
No. Information Type of In-
formation
Comments
