2 Functions
70
7SD5 Manual
C53000-G1176-C169-1
1162 VECTOR GROUP I 0 .. 11 0 Vector group numeral for
current
1163 TRANS STP IS Solid Earthed
Not Earthed
Solid Earthed Transformer starpoint is
1540 Distance Angle 30 .. 90 ° 85 ° Angle of inclination, dis-
tance charact.
6001 S1: Line angle 30 .. 89 ° 85 ° S1: Line angle
6002 S1: x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S1: feeder reactance per
km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6002 S1: x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S1: feeder reactance per
mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6003 S1: c' 1A 0.000 .. 100.000 µF/km 0.010 µF/km S1: feeder capacitance c'
in µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6003 S1: c' 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S1: feeder capacitance c'
in µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6004 S1: Line length 0.1 .. 1000.0 km 100.0 km S1: Line length in kilome-
ter
6004 S1: line length 0.1 .. 650.0 Miles 62.1 Miles S1: Line length in kilome-
ter
6008 S1: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S1: center phase
6009 S1: XE/XL -0.33 .. 7.00 1.00 S1: Zero seq. compensat-
ing factor XE/XL
6010 S1: RE/RL -0.33 .. 7.00 1.00 S1: Zero seq. compensat-
ing factor RE/RL
6011 S1: K0 0.000 .. 4.000 1.000 S1: Zero seq. compensat-
ing factor K0
6012 S1: angle K0 -135.00 .. 135.00 ° 0.00 ° S1: Zero seq. compensat-
ing angle of K0
6021 S2: Line angle 30 .. 89 ° 85 ° S2: Line angle
6022 S2: x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S2: feeder reactance per
km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6022 S2: x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S2: feeder reactance per
mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6023 S2: c' 1A 0.000 .. 100.000 µF/km 0.010 µF/km S2: feeder capacitance c'
in µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6023 S2: c' 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S2: feeder capacitance c'
in µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6024 S2: Line length 0.1 .. 1000.0 km 100.0 km S2: Line length in kilome-
ter
6024 S2: line length 0.1 .. 650.0 Miles 62.1 Miles S2: line length in miles
Addr. Parameter C Setting Options Default Setting Comments
