WORKSHOP MANUAL
EDITION
PAGE
28 /
124
2. Unscrew the two nuts (2) and remove the hood
(1) by sliding it off the support hinge (3).
When assembling, pay attention to position the
plastic washer (4) on the side of the support
(3).
The front casing (1) consists of two el-
ements connected together by a screw, located
on the left side. The following procedure provides
for the removal of the two assembled elements,
which can be separated later.
1. Unscrew the right screw (2)
