WORKSHOP MANUAL
EDITION
PAGE
48 /
124
1. Lift the rear part and stabilize the machine
.
2. Disconnect the connector (1) from the power
cable of the electromagnetic clutch (2).
5.1.1 Clutch removal ..............................................................................48
5.1.2 Removal of the engine ..................................................................49
5.1.3 Removal and replacement of the exhaust muffler .........................51
5.1.4 Replacement of the throttle ...........................................................52
5.1.5 Replacement of the throttle cable .................................................54
5.1.6 Replacement of the choke cable ..................................................55
5.2.1 Removal and replacement of the tank ..........................................56
