WORKSHOP MANUAL
EDITION
PAGE
61 /
124
▶▶
Engine / transmission belt
.
Engine / articulated joint axis
belt .
6.3.1
1. Remove the electromagnetic clutch from the
engine shaft
2. Press the brake pedal to loosen the belt (1)
and be able to free it from the pulley (2).
3. Release the brake to make the screw (3) for
securing the tightener (4) accessible, unscrew
the nut (5) and remove the tightener (4).
