The engine is made to precise technical specifi-
cations which differentiate it from similar items by
this same Manufacturer.
The engine has one or two labels (1) with serial
number that clearly identifies the product and its
specifications; this number must always be quot-
ed when requesting spare parts or any informa-
tion from the Manufacturer.
Given the possibility of using different
engines, the image is only an example.
Depending on the version, the ma-
chine is equipped with one or two
hydrostatic transmission units.
This units are made by another
manufacturer according to precise
technical specifications which dif-
ferentiate them from similar items
by this same Manufacturer.
Each transmission unit has a label
(1-front, if present) and (2-back)
with a serial number that clearly
identifies the product and its spec-
ifications; this number must always be quoted when requesting spare parts or any information
from the Manufacturer.
This manual includes assistance and maintenance operations for a range of machines, which
differ from each other in terms of engines, components and equipment; differences and common
elements are highlighted in the technical data table.
All STIGA machines have been subjected to an accurate programme of checks before delivery.
The machine are supplied at their most complete level and thanks to this the final assembly for
the delivery is quick and easy.
The correct and accurate assembly of the machine upon delivery is an easy way to ensure satis-
fied customers!
The machine has to remain positioned on the pallet during the unpacking and assembly.
