A Trigger Event configuration menu

Use this menu to set the trigger conditions for the A trigger event of a Sequence trigger.

To open the A Trigger Event menu:

1. Double-tap the Trigger badge on the Settings bar.

2. Set the Trigger Type to Sequence.

3. Tap the A Trigger Event button.

A Trigger Event menu (Sequence Trigger configuration menu) fields and controls.

Field or control Description

Trigger Type Select the A event trigger type.

Other fields and controls The fields and controls shown depend on the selected Trigger Type. Use the following links to

access setting information on a specific trigger.

■

Bus Trigger Menu

■

Edge Trigger menu

■

Logic Trigger

■

Pulse Width Trigger menu

■

Rise/Fall Time Trigger menu

■

Runt Trigger menu

■

Sequence Trigger menu

■

Setup & Hold Trigger menu

■

Timeout Trigger menu

■

Window Trigger menu

NOTE. The Sequence Trigger type is not available in the A Trigger Event menu.

B Trigger Event configuration menu

Use this menu to set the trigger conditions for the B trigger event of a Sequence trigger.

To open the B-Trigger Event configuration menu:

1. Double-tap the Trigger badge on the Settings bar.

2. Set the Trigger Type to Sequence.

3. Tap the B Trigger Event button.

Menus and dialog boxes

394 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
