Field or control Description
Mark When Sets the mark when condition.
Only available when Mark On = Data or ID & Data.
A, B knob controls Use the A knob to select (highlight) the digit to change.
Use the B knob to change the value of the digit.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Ethernet serial bus search configuration menu
Use the Ethernet Search configuration menu to define conditions to search for and mark on an Ethernet bus waveform. You can
have multiple searches on the same bus.
NOTE. Requires option SRENET.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the Ethernet bus that you want to search.
Mark On Select the type of information for which to search.
MAC Address Destination,
MAC Address Source
Sets the MAC destination and/or source address pattern for which to search.
Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Mac Addresses.
Q-Tag Sets the Q-tag pattern for which to search.
Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Q-Tag Control Information.
MAC Length/Type Enter the MAC length or type pattern for which to search. Use in conjunction with the Mark
When field to specify the exact search condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = MAC Length/Type.
Menus and dialog boxes
