Reelmaster 7000−D Hydraulic SystemPage 5 − 31

Troubleshooting

The charts that follow contain information to assist in hy-

draulic system troubleshooting. There may possibly be

more than one cause for a machine malfunction.

Refer to the Testing section of this Chapter for precau-

tions and specific testing procedures.

General Hydraulic System Problems

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Problem

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Possible Cause

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Hydraulic system operates hot.

NOTE: An indication that the hy-

draulic system is operating at exces-

sive temperatures would be frequent

reversing of the cooling fan and a

normal engine coolant temperature.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Engine RPM is too low.

Hydraulic reservoir oil level is low.

Hydraulic oil is contaminated or the wrong type.

Brakes are applied or sticking.

Piston pump bypass valve is open or damaged.

Cooling system is not operating properly.

Charge pressure is low.

Engine cooling fan circuit is malfunctioning (see Engine Cooling Fan

Circuit Problems in this section).

Traction circuit pressure is incorrect.

Pump(s) or motor(s) are damaged.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Hydraulic oil in reservoir foams.

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Hydraulic reservoir oil level is low.

Wrong type of oil is in the hydraulic system.

Air is leaking in suction line.

ÁÁÁÁÁÁÁÁÁÁÁÁÁ

Hydraulic oil leak(s).

ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ

Fitting(s), hose or tube loose or damaged.

Missing or damaged O-ring in fitting.
