Reelmaster 7000
−
D
Page 3
−
23
Y
anmar Diesel Engine
Pump Adapter Plate
Figure 16
1. Flywheel
plate
2.
Hardened washer (8)
3. Spring
coupler
4.
Cap screw with patch lock (8)
5.
Cap screw with patch lock (8)
6.
Hardened washer (8)
7. Engine
assembly
FRONT
RIGHT
1
3
5
2
4
6
7
17 to 21 ft
−
lb
(23 to 28 N
−
m)
Boss
Loctite #242 (if reused)
Loctite #242 (if reused)
Y
anmar
Engine
44
46
