Reelmaster 7000−D Page 6 − 19 Electrical System
About Screen
The about screen (Fig. 19) identifies the machine model
number, serial number and software revision for the ma-
chine. If the correct passcode (PIN) has been entered
(see Settings Screen − Protected Menus in this chap-
ter), the Toro Electronic Controller (TEC), InfoCenter,
and engine ECU software is displayed, and the CAN−
bus status will be visible. Press the Down button to scroll
through the screen items (as indicated by the
at the
bottom of the screen). The information found in the
about screen can only be edited by your Toro Distributor.
To return to the previous screen, press the Menu/Back
button (as indicated by the
at the bottom of the
screen).
Figure 19
About
Model:
SN:
S/W Rev:
03780
315000113
122−0251A
3
2
1
1. Screen items
2. Down button
3. Menu/Back button
Counts
122−0241B
<N/A>
Normal
PIN
3
2
1
ABOUT SCREEN
Electrical
System
