Toro 03721 Service Manual

Reelmaster 7000--D
DPA Cutting Units
Page 9 -- 1
Chapter 9
DPA Cutting Units
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 3.....................
Cutting Unit Operator’s Manual 3...............
SPECIAL TOOLS 4.............................
FACTORS THAT CAN AFFECT CUTTING
PERFORMANCE 9............................
ADJUSTMENTS 12.............................
Characteristics 12.............................
Reel Bearing Adjustment
(cutting units with painted side plates) 13.......
Leveling Rear Roller 14........................
SERVICE AND REPAIRS 16.....................
Hydraulic Reel Motor 16.......................
Backlapping 17...............................
Bedbar Assembly 18..........................
Bedknife Replacement and Grinding 20..........
Bedbar Adjuster Service 22....................
Reel Assembly
(cutting units with painted side plates) 24......
Reel Assembly Service
(cutting units with painted side plates) 28......
Reel Assembly
(cutting units with aluminum side plates) 30....
Reel Assembly Service
(cutting units with aluminum side plates) 34....
Preparing Reel for Grinding 36.................
Front Roller 38...............................
Rear Roller 39................................
Roller Service 40.............................
Rear Roller Brush -- Optional
(cutting units with painted side plates) 42......
Rear Roller Brush -- Optional
(cutting units with aluminum side plates) 46....
DPA Cutting
Units
