Reelmaster
7000
-
D
Hydrau
lic
System
Page
5
-
126
Steer
ing
Cylinder
1.
Steering
cylinder
2.
Ball
joint
3.
Ball
joint
4.
Retaining
ring
5.
Grease
fitting
6.
Grease
fitting
7.
90
o
hydraulic
fitting
8.
O
-
ri
ng
9.
O
-
ri
ng
10.
Drive
axle
assembly
1
1.
Ball
joint
spacer
12.
Axle
washer
13.
Slotted
hex
nut
14.
Cot
ter
p
in
15.
Hydr
aulic
hose
16.
Hydr
aulic
hose
Figure
83
6
4
1
2
10
5
4
3
12
14
11
13
7
8
9
9
100
to
125
ft
-
lb
(136
to
169
N
-
m)
FRONT
RIGHT
7
14
15
16
195
