Toro 03721 Service Manual

Reelmaster 7000−D Page 3 − 13 Yanmar Diesel Engine
Fuel System
1. Fuel suction tube
2. Fuel line clamp (2)
3. Fuel hose (tank to pump)
4. Return fitting
5. Fuel hose (engine to tank)
6. Fuel tank cap
7. Bushing (2)
8. Hose clamp (6)
9. Fuel tank
10. Cap screw (2)
11. Clamp (2)
12. Flange nut (2)
13. Fuel pump
14. Cap screw
15. Fuel hose (pump to filter)
16. Fuel hose (filter to engine)
17. Cap screw (2)
18. Flange nut (4)
19. Fuel/water separator
20. Filter element
21. Elbow fitting (2)
22. Flat washer (2)
23. Fuel gauge
24. Grommet
25. Hose clamp
26. Draincock
Figure 8
FRONT
RIGHT
12
22
11
10
25
26
Return From Engine
To Engine
1
2
3
4
5
6
7
8
9
23
24
18
13
14
15
16
17
19
20
21
21
8
8
8
8
Thread
Sealant
Thread Sealant
Yanmar
Engine
