Toro 03721 Service Manual

Reelmaster 7000−DPage 8 − 12Chassis
Operator Seat
Figure 10
FRONT
RIGHT
25
21
23
24
22
17
30
29
26
27
28
19
20
18
1
3
8
2
6
5
7
14
13
9
10
11
12
6
4
6
9
15
16
1. Hex head screw
2. Spacer
3. Seat belt buckle
4. Flat washer (3)
5. Operator seat
6. Carriage screw (4)
7. Hex head screw
8. Coupling nut
9. Flange nut (4)
10. Console arm support
11. Support channel
12. Grommet or foam seal
13. Manual tube
14. Clamp (2)
15. Cap screw (2)
16. Flange nut (2)
17. Seat belt
18. Hex head screw
19. Flange head screw (4)
20. Flange nut (4)
21. Seat plate
22. Seat frame
23. Latch
24. Spring
25. Cotter pin
26. Flat washer
27. Clevis pin
28. Support rod (2)
29. Hair pin (4)
30. Flat washer (2)
31. Flange head screw (4)
32. Hair pin
33. Pivot shaft
34. Flange nut (4)
4
4
28
29
31
32
33
34
