Reelmaster 7000−D
Page 4 − 22
Kubota Diesel Engine
Pump Adapter Plate
Figure 18
1. Bolt
2. Lock
washer
3. Flywheel
plate
4.
Hardened washer (14)
5. Spring
coupler
6.
Cap screw with patch lock (6)
7.
Cap screw with patch lock (8)
FRONT
RIGHT
1
2
3
4
5
6
7
4
Loctite #242 (if reused)
Boss
Loctite #242 (if reused)
29 to 33 ft−lb
(40 to 44 N−m)
67
69
