17 Technical data
17.1 Technical data
General
IP IP20 (IP: degree of inaccessibility to active parts of the product
and degree of water)
Max. ambient RH (relative humidity) 85% at 20 °C
Thermostat and timer
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply Two 1.5 V AAA alkaline batteries
Voltage 2.2 V to 3.6 V
Operating temperature 0 °C to +45 °C
Storage temperature -10 °C to +65 °C
Radio frequency 868.3 MHz
Transmitter duty cycle <1%
Connection terminals (thermostats only) 0.5 mm² to 2.5 mm²
Interface (Wave PLUS only)
CE marking
Low voltage tests EN 60730-1 and EN 60730-2-1
EMC (electromagnetic compatibility requirements) tests EN 60730-1
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply 230 V AC +10/-15%, 50 Hz in wall box or
mini USB connection
Operating temperature 0 °C to +45 °C
Storage temperature -20 °C to +70 °C
Controller/interface SD card (Wave PLUS only)
Type micro SDHC, UHS or Standard
Capacity 4 GB to 32 GB, FAT 32 formatting
Speed Class 4 to 10 (or higher)
Relay module
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-1***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply 230 V AC +10/-15%, 50 Hz or 60 Hz
Operating temperature 0 °C to +50 °C
Storage temperature -20 °C to +70 °C
Maximum consumption 2 W
Relay outputs 230 V AC +10/-15%, 250 V AC 8 A maximum
Power connection 1 m cable with europlug (except UK)
Connection terminals Up to 4.0 mm² solid, or 2.5 mm² flexible with ferrules
UK
CZ
DE
DK
EE
ES
FI
FR
HR
HU
IT
LT
LV
NL
NO
PL
PT
RO
RU
SE
SK
90
UPONOR SMATRIX WAVE/WAVE PLUS · INSTALLATION AND OPERATION MANUAL
