Uponor Smatrix Wave PLUS User Manual

Antenna
Power supply From controller
Radio frequency 868.3 MHz
Transmitter duty cycle <1%
Receiver class 2
Controller
CE marking
Low voltage tests EN 60730-1* and EN 60730-2-1***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3
Power supply 230 V AC +10/-15%, 50 Hz or 60 Hz
Internal fuse T5 F3.15AL 250 V, 5x20 3.15A quick acting
Internal fuse, Heat pump output TR5-T 8.5 mm Wickmann 100 mA Time lag
Operating temperature 0 °C to +45 °C
Storage temperature -20 °C to +70 °C
Maximum consumption (Wave) 40 W
Maximum consumption (Wave PLUS) 45 W
Pump and boiler relay outputs 230 V AC +10/-15%, 250 V AC 8 A maximum
General purpose input (GPI) Only dry contact
Heat pump input (Wave PLUS only) 12 – 24 V DC /5 – 20 mA
Heat pump output (Wave PLUS only) 5 – 24 V DC /0.5 – 10 mA, current sink ≤ 100 mW
Valve outputs 24 V AC, 0.2 A average, 0.4 A peak
Power connection 1 m cable with europlug (except UK)
Connection terminals for power, pump, GPI and boiler Up to 4.0 mm² solid, or 2.5 mm² flexible with ferrules
Connection terminals for valve outputs 0.2 mm² to 1.5 mm²
*) EN 60730-1 Automatic electrical controls for household and similar use
-- Part 1: General requirements
**) EN 60730-2-1 Automatic electrical controls for household and similar use
-- Part 2-1: Particular requirements for electrical controls for electrical
household appliances
***) EN 60730-2-9 Automatic electrical controls for household and similar use
-- Part 2-9: Particular requirements for temperature sensing controls
17.2 Technical specifications
Cables Standard cable length Maximum cable length Wire gauge
Cable from controller to antenna 0.50 m 5 m CAT.5e or CAT.6, RJ 45 connector
Cable from controller to actuator 0.75 m 20 m Controller: 0.2 mm² to 1.5 mm²
External sensor cable to thermostat 5 m 5 m 0.6 mm²
Floor sensor cable to thermostat 5 m 5 m 0.75 mm²
Outdoor sensor cable to thermostat - 5 m Twisted pair
Cable from relay switch to controller
GPI input
2 m 20 m Controller: Up to 4.0 mm² solid, or 2.5 mm²
flexible with ferrules
Relay: 1.0 mm² to 4.0 mm²
Cable to/from heat pump to controller
heat pump input/output (Wave PLUS
only)
- 30 m Twisted pair
0682
Usable in all Europe
Declaration of conformity:
We hereby declare under our own responsibility that products dealt
with by these instructions satisfy all essential demands linked to the
R&TTE 1999/5/CE Directive dated March 1999.
UK
CZ
DE
DK
EE
ES
FI
FR
HR
HU
IT
LT
LV
NL
NO
PL
PT
RO
RU
SE
SK
91
UPONOR SMATRIX WAVE/WAVE PLUS · INSTALLATION AND OPERATION MANUAL
