Control Panel Menus
WorkCentre 6505 Color Laser Multifunction Printer
User Guide
162
Scan Defaults
Use this menu to set default scanning behaviors. For details, see Adjusting Scanning Options on
page 120.
Special Copy Mode Use to copy two original page images onto one side of a sheet of paper:
•None
•2-up (Autoscale)
•ID Card Copy
•2-up (Manual Scale)
Margin Top/Bottom Turns on and off the copy margins for the top and bottom of the page.
Margin Left/Right Turns on and off the copy margins for the left and right of the page.
Margin Middle Turns on and off the copy margins for the middle of the page. Use to create a gutter in
the middle of the page when you print using the N-up feature.
Item Description
Scan to Network Selects the scan destination: Computer (Network) or Server (FTP).
File Format Selects the file type of the scanned image.
Color Selects the color mode: Color or Black and White.
Color Button Set Adjusts the Color Mode settings:
• B&W button: Black & White or Grayscale.
• Color Button: Color or Color (Photo)
Resolution Selects the scan resolution.
Document Size Specifies the size of the original document.
Lighten/Darken Lightens or darkens the scanned image.
Sharpness Specifies the sharpness of the scanned image.
Contrast Specifies the contrast of the scanned image.
Auto Exposure Turns Auto Exposure on and off when scanning. Auto Exposure suppresses the
document background of off-white colored paper. It also helps suppress show-through
when copying 2-sided thin paper.
Auto Expo. Level Adjusts the level of the auto exposure functionality.
Margin Top/Bottom Turns on and off the copy margins for the top and bottom of the page.
Margin Left/Right Turns on and off the copy margins for the left and right of the page.
Margin Middle Turns on and off the copy margins for the middle of the page. Use to create a gutter in
the middle of the page when you print using the N-up or booklet features.
TIFF File Format Sets the TIFF file format: TIFF V6 or TTN2.
Item Description
